ViewBoard® 86" 4K Interactive Display
Integrated with myViewBoard software
Multi-tasking capabilities for enhanced lesson delivery
Embrace simplicity and organization with the USB-C one-cable solution, offering 65W of Power Delivery.
Intuitive user interface and fast app launch for smooth operation
Powered by Android 11
* Price excludes taxes, shipping, installation, setup, service fees, and additional charges. Contact sales for a customized quote.
The ViewBoard IFP33 Series harmonizes a touch display with versatile software to create a comprehensive classroom solution for interactive and engaging learning. This interactive flat panel delivers exceptional image quality in 4K UHD, thanks to cutting-edge bonding technology that provides clearer colors, enhanced contrast, and reduced glare. The 40-point touchscreen interface, equipped with Ultra Fine Touch Technology, empowers students and teachers to collaborate seamlessly, using either their fingers or dual-tip pens, for an intuitive pen-on-paper experience. Powerful built-in front-facing speakers and a USB-C port sort out for a complete and convenient multimedia experience. The ViewBoard IFP33 Series is preinstalled with myViewBoard to offer advanced lesson delivery options for teachers and powerful device management tools for administrators.
Access to Google Play Store and Workspace suite with Android™ 14 launcher.
Runs on the latest Android operating system for smooth performance
High-performance octa-core processor for fast operation
8GB DDR4 RAM for smooth multitasking
128GB storage for apps and content
Ultra HD 3840x2160 resolution for stunning visuals
40-point multi-touch for seamless collaboration
Automatic Android security and application updates for a protected environment.
Enhance lessons with split-screen, Picture-in-Picture, and Picture-by-Picture modes.
40-point Ultra-Fine Touch, dual-pen capabilities, and enhanced pen-on-paper feel.
One-cable solution for multimedia playback, data transfer, and 65W power delivery.
Seamlessly prepare, save, and share class materials across various platforms.
myViewBoard Display for instant casting and vCast app for advanced features.
Built-in dual 16W front-facing speakers for profound audio depth.
myViewBoard Manager for secure remote management of multiple displays.
Upgrade capabilities with an optional slot-in PC, featuring an Intel Core CPU.
| Display | Panel Size: 86" Panel Type: TFT LCD module with DLED backlight, VA Display Area (mm): 1913.04(H) x 1083.96 (V) Aspect Ratio: 16:9 Resolution: UHD 3840x2160(Pixels) Colors: 1.07B colors Brightness: 350 nits Contrast Ratio: 5000:1 (max. with DCR enabled) Response Time: 8ms Viewing Angles: H=178, V=178 Backlight Life: 50,000 Hours (8 hours of use per day) Surface Treatment: Hardness: 7H Anti-glare coating Orientation: Landscape |
| Platform | Processor: Quad-core ARM Cortex (A55*4 ) RAM: 8GB DDR4 Storage: 128 GB |
| Touch | Type/ Tech: Ultra Fine Touch Technology Touch Point: 40 points touch |
| INPUT | HDMI: HDMI-IN 2.0 x 3 (3840x2160 @60Hz) RGB / VGA: x1 Audio: x1 RS232: x1 OPS: x1 (Optional Intel Standard OPS) WiFi: x1 (Optional VB-WIFI-002/VB-WIFI-004/VSB-050) |
| OUTPUT | HDMI: HDMI 2.0 x1 Audio: x1 SPDIF: x1 |
| LAN | RJ45: x2 |
| USB | Type A: USB3.0 x4 (Front x2, Rear x2)； USB2.0 x1 Type B: x2 (Front x1, Rear x 1) Type C: Front*1 (PD65W + DP1.2 + Data USB2.0 + 10M/100M sharing) |
| SPEAKERS | 16W x 2 |
| Top Camera Plate | Yes |
| Embedded OS | Android 11 |
| Bundle Software | Basic Annotation Software: myViewBoard Whiteboard Pro Annotation Software: myViewBoard for Windows (Embedded in optional Windows Slot-in PC) Wireless Presentation: myViewBoard Display Wireless Presentation with Touch Feedback: Viewboard Cast: Yes |
| Special Features | All-in-one USB port: (combine slot-in PC/Android/HDMI USB port) Front “SmartPort™ USB” to all channels. Simple LAN sharing between IFP and slot-in device: 10/100M for Android & Slot-in PC Light Sensor: Yes |
| Power | Voltage: 100-240V AC Consumption: On:154W ; Off: ≤ 0.5W |
| ERGONOMICS | Wall Mount (VESA® ): 800*600 |
| OPERATING CONDITIONS | Temperature (º C): 0°C to 40°C Humidity: 20% ~ 80% RH non-condensing |
| DIMENSIONS (W x H x D) | Physical (inch / mm): 1957 x 1160 x 100 mm / 77 x 45.7 x 3.9 in Packaging (inch / mm): 2110 x 1283 x 225 mm /83 x 50.5 x 8.9 in |
| WEIGHT | Net (lb / kg): 129.1lb/58.55kg Gross (lb / kg): 167.3lb/75.9kg |
| REGULATIONS | FCC/ICES003, EPEAT, CE EMC, LVD or CB, RoHS Green BOM & RoHS DoC, ErP, REACH SVHC List & DoC, EEL, WEEE, BSMI,BIS |
| PACKAGE CONTENTS | 1. 3m power cord by ship area 2. Remote control with AAA battery 3. 3m touch USB cable 4. Touch pen x 2 (VB-PEN-009) 5. Quick Start Guide + Compliance statement 6. RS232 adapter 7. Clamp x 5 8. Camera Plate 9. Screw x 8 (camera 2+2, wall mount 4) 10. HDMI cable 3m |
| Compatible Slot-in PC | VPC2-O series/VPC2-O-1B series/VPC12-WPO-15/16 |
