PA503S-3 Business Projector

The ViewSonic PA503S-3 is a high-performance SVGA projector designed for small business meeting rooms and classrooms. With 4,000 ANSI Lumens of brightness and a 28,000:1 contrast ratio, it delivers clear, detailed images regardless of ambient lighting conditions.

Featuring ViewSonic's exclusive SuperColor™ Technology, the PA503S-3 offers a wider range of displayable colors with true-to-life accuracy. Users can choose from 5 color modes - standard, brightest, presentation, photo, and movie mode - to optimize the display for different usage scenarios.

The energy-saving SuperEco mode reduces power consumption and extends lamp life up to 15,000 hours, while automatic power-off and sleep timer features help conserve energy when the projector is not in use.

Download Brochure

* Price excludes taxes, shipping, installation, setup, service fees, and additional charges. Contact sales for a customized quote.

Product Features

A versatile business projector designed for small meeting rooms and classrooms, featuring high brightness, extended lamp life, and advanced color technology.

High Brightness

4,000 ANSI Lumens with 28,000:1 contrast ratio

SuperColor™ Technology

True-to-life color accuracy with 5 color modes

Extended Lifespan

Up to 15,000 hours in SuperEco mode

Auto Power Off

Automatic shutdown when no signal detected

Instant Activation

Direct power on and signal power on options

Vertical Keystone

±40° vertical image correction

Smart Tools

Presentation timer and blank timer features

Multi-language

22 OSD languages supported

Technical Specifications

Projection System	0.55" SVGA
Native Resolution	800x600
Brightness	4,000 ANSI Lumens
Contrast Ratio	28,000:1 (with SuperEco Mode)
Display Colors	1.07 Billion Colors
Light Source	190W Lamp
Lamp Life	6,000 hours (Normal) / 15,000 hours (SuperEco)
Throw Ratio	1.96-2.15
Image Size	30"-300"
Throw Distance	1.19m-13.11m (100"@3.98m)
Keystone	±40° (V)
Optical Zoom	1.1x
Connectivity
Input Ports	Computer in (2), HDMI (1), Audio-in (1)
Output Ports	Monitor out (1), Audio-out (1)
Control Ports	RS232 (1), USB Type Mini B Service (1)
Physical Specifications
Dimensions (WxDxH)	294x218x110mm (with Adjustment Foot)
Net Weight	2.2kg
Power Consumption	260W (Normal) / <0.5W (Standby)
Operating Temperature	0~40℃
