The ViewBoard IN7501-G is the interactive flat panel that delivers exceptional image quality in 4K UHD, thanks to cutting-edge bonding technology that provides clearer colors, enhanced contrast, and reduced glare.
The 40-point touchscreen interface, equipped with Ultra Fine Touch Technology, empowers students and teachers to collaborate seamlessly, using either their fingers or dual-tip pens, for an intuitive pen-on-paper experience. Powerful built-in speakers and a USB-C port sort out for a complete and convenient user experience.
* Price excludes taxes, shipping, installation, setup, service fees, and additional charges. Contact sales for a customized quote.
A state-of-the-art interactive flat panel designed for modern educational institutions, featuring advanced technology for interactive and engaging learning experiences.
Latest Android operating system for smooth performance
Crystal clear 3840x2160 pixels display
40-point touch for seamless collaboration
20W x 2 front-facing speakers for immersive audio
DDR4 memory for smooth multitasking
Ample space for apps and content
ARM Cortex A55 for powerful performance
9H hardness for durability and reduced reflections
| Panel Size | 75" |
| Panel Type | TFT LCD Module with DLED Backlight, ADS |
| Display Area (mm) | 1649.664(H) × 927.936(V) |
| Aspect Ratio | 16:9 |
| Resolution | UHD 3840x2160(Pixels) |
| Colors | 1.07B colors |
| Brightness | 450 nits |
| Contrast Ratio | 5000:1 |
| Response Time | 8ms |
| Viewing Angles | H=178, V=178 |
| Backlight Life | 50,000 Hours |
| Surface Treatment | Hardness: 9H Anti-glare coating |
| Orientation | Landscape |
| Processor | Octa-core ARM Cortex (A55*8) |
| RAM | 8GB DDR4 |
| Storage | 128GB |
| Touch Technology | Ultra Fine Touch Technology |
| Touch Points | Windows: 40 Android: 40 |
| HDMI | x3 (Frontx1:HDMI2.0 ; Rearx2 [(HDMI2.0 with CEC/ARC)x1, (HDMI2.0 with CEC)x1]) |
| RGB / VGA | x1 |
| Audio | x1 |
| RS232 | x1 |
| OPS | x1 (Optional Intel Standard OPS) |
| WiFi | x1 (Built-in) |
| HDMI Output | x1 |
| Audio Output | x1 |
| SPDIF | x1 |
| LAN RJ45 | x1 |
| USB Type A | USB3.0:Front x1, Rear x1; USB2.0:Front x1, Rear x1 (Support OTG) |
| USB Type B | USB 2.0:Front x1, Rear x1 |
| USB Type C | USB 2.0:Front x1 |
| Speakers | 20W x 2 |
| Embedded OS | Android 14 |
| Special Features | All-in-one USB port: (combine slot-in PC/Android/HDMI USB port) Front "SmartPort™ USB" to all channels. |
| Voltage | 100-240V AC |
| Consumption | On: 245W Off: <0.5W |
| Wall Mount (VESA®) | 600*400 |
| Temperature (º C) | 0°C to 40°C |
| Humidity | 20% ~ 80% RH non-condensing |
| Physical Dimensions (inch / mm) | 67.54x40.23x3.69(in) / 1715.6x1021.9x93.7 (mm) |
| Packaging Dimensions (inch / mm) | 72.17x45.60x7.87(in) / 1833x1158x200 (mm) |
| Net Weight (lb / kg) | 101.4lb/43.0kg |
| Gross Weight (lb / kg) | 121.9lb/55.3kg |
| Regulations | BIS |
| Package Contents | 1. 3m power India power plug x 1 2. 3m HDMI cable x 1 3. 3m Touch USB cable (USB2.0) x 1 4. Touch pen x 2 5. Retractable stylus x 1 6. WiFi Dual band antenna x 2 7. Remote control x 1 8. AAA battery x 2 9. Quick Start Guide with Compliance statement 10. Screw x 4 (wall mount M8*25mm) |
| Compatible Slot-in PC | VPCF5-W55-G1 / VPC37-W53-G1 / VPC35-W53-G1 |
